MetroLinq™ 60 LW

MetroLinq™ 5 LW

Cloud-enabled Outdoor 5 + 2.4 GHz PTP/ PTMP

IgniteNet’s MetroLinq 5 LW is a dual-band and dual-radio wireless bridge ideal for PTP and PTMP connections. With a range of up to 2km (1.24mi) from MetroLinq 10G Omni base-station it is an ideal device to connect more remote and lower capacity fixed wireless clients.

The MetroLinq 5 LW also includes a 2.4 GHz radio which can be configured a multi-tenant AP for applications ranging from hotspots to maintenance and many more. Integrated dual- radio design allows saving tower space and covers wireless backhaul and local Wi-Fi access scenarios with the same stock keeping unit.

How To Buy

Main applications



60 GHz network extension

Connect more distant and lower capacity 5 GHz clients to your existing 60 GHz networks.



Wireless bridge with Wi-Fi

Build short to mid-range wireless bridges with an option to provide local Wi-Fi access using the same device.

Mounting bracket

Power passthrough

When the MetroLinq 5 LW is powered using the supplied PoE adapter, the DC screw terminal may be using to feed other devices such as IP cameras or other peripheral device including smart city or IoT network gateways.

Powerful OS

The advanced operating system has a professional feature-set required to do ultra high speed point-to-point and point-to-multipoint communications. It includes 128 bit AES encryption for security, jumbo frame support, advanced 5 GHz failover capabilities and many more. Each base-station can be configured individually as well as centrally using our cloud based controller.

Mounting bracket

Simple to setup and control

The MetroLinq 5 LW has instant, out of the box cloud support and can be remotely managed and monitored. The cloud controller from IgniteNet is a powerful and cost-effective platform to monitor and manage multiple networks and types of devices and supports unlimited devices for only $99 USD per year.

Multiple base-station options

Multiple base-station options with different sized integrated antennas are available to support different distances and applications when using MetroLinq 5 LW in multi-gigabit wireless networks.

ML Omni

ML 10G Omni

2km (1.24 mi)
ML LW

ML 2.5G BF sector

1km (0.62 mi)
ML 19cm

ML 60 LW*

1km (0.62 mi)
ML 35cm

ML 5 LW

10km (6.2 mi)

Note: The Distance may vary due to rain rate differences in your region.
